A2K-TER-M - NMEA 2000 Terminator

The Actisense NMEA 2000 A2K-TER-F terminator is for use at each end of an NMEA 2000 backbone to ensure proper operation and signal integrity.

The terminators have been designed by Actisense for quick and easy installation.

This terminator has a very robust design.

The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge. All Actisense products are NMEA 2000 certified and fully compatible with other NMEA 2000 connectors and devices.

All Actisense connectors follow the DeviceNet® standard.

Technical Specification

Electrical

• Rated Current: 4 A
• Rated Voltage: 25 V (AC/DC)

Mechanical

• Male Contact: Brass, gold plated
• Contact Carrier: PBT, black
• Contact Polarization: Standard M12 - "A" - Polarization
• Mating Thread: M12
• Screw Cap: Brass, nickel plated
• Housing: PVC, black
• Weight: 13g

Approvals and Certifications

• Protection: IP67 (when mated)
• Operating Temperature: - 20°C to + 70°C
• Storage Temperature: - 40°C to +85°C
• NMEA 2000 Certified
• RoHs Compliant
• UL Certified (UL1277)
